## EQLocate

Novice

EqLocate is an interactive app that allows users to locate earthquakes using real seismic data. The event list includes the latest earthquake in the news, as well as selected historic mega earthquakes. Users select the stations to include in the location process, conduct quality control on the waveforms, pick seismic arrivals, and apply one of the three included location methods to find a solution. User solutions are then compared to the USGS accepted solution. Users can explore historic seismicity in the region where they located the event by seamlessly connecting to the IRIS Earthquake Browser (IEB).

Earthquake Location Methods

• Residual Minimization (Coming Soon) - A more modern computer based approach to locating earthquakes based only P wave arrivals from many seismic stations. Using a mathematical model, P wave arrival times are predicted for trial event locations, which are then refined through comparisons to the user-selected arrivals.
• Perpendicular Bisector - An intuitive geometric approach to locating earthquake using only P wave arrivals from many seismic stations.
• S-P Travel Time Coming Soon) -  The classic geometric approach to locating earthquakes using differences between the arrivals of S and P waves from at least three seismic stations.

#### Keypoints:

• Locate both recent earthquakes from a US or global list, and select historic events
• Locate earthquakes using real seismic data
• Three different methods to locate earthquakes
• Interactive e-learning tutorials available for each location method (coming soon)
